■ Assembly of Main Unit

PCB ASSY

Main PCB Ass'y

Insert

it before setting

the

Main Board.

Audio

FPC Ass'y

Apply

the lubricant (sub material) on the

HDD

Connector for about 1 second.

(Note

for spraying around when applying.)

Audio

FPC Ass'y

1mm

Safety

critical componentInsert

and

then lock.

Audio

FPC

Tape

Screw

Thermal

Sheet

Wireless

Module

Lengthwise

Fold

back

Stiffening

Plate Side

Center

of module

the notch

Insert

and then lock

Insert

and then lock.

Connect

Round

to make the brown side

outside

and insert the notch.

S1:Insulation

S2:Pinching Cables S3:Sharp Edge

S4:Part

No. Check S5:Others

Safety

Working

CAUTION

Attach

it on the

center

of the

FPC.

3mm

Important

Parts

for

Safety
