■ Assembly of the HDD ASSY
Heater Ass'y
Heater Assy
Note for the Heater top end location
Two-sided Tape
Come the bottom over by 0 to 0.5 mm.
Attach on the inside of 1
Details for attachment of Heater Insulation Sheet
Sub material: Pet Tape 1
(19mm width x 4 cm)
Safety Working
Avoid any stress
Heater
Insulation Parts
Insulation Parts
FPC(HDD)
Thermal Sheet
Heater Insulation Sheet
Revision Label
HDD
0
2mm
0 0.5mm
0 1mm
10 15mm
5 1mm
5 1mm
1 2mm
Match to the level.
0 to 1 mm
2mm
Matches to
the center
Round to make the brown side
outside and insert the notch part
Connect the Connector
Back
Attach it on the center of the HDD.
3mm
Attach on the inner side
of the HDD Case A
Make the Hook inside
Hook it
HDD Case Upper HDD Damper
HDD Case Lower
HDD Case Lower
HDD Case Tab
HDD Connector Guard
Screw
Screw
FPC Connector
Insulation Sheet
0 0.5mm
Attach
Production
Remove the
Release Paper
