Page 54
SD
PCB Ass'y
DIMM
HOLDER Ass'y
Ensure
that the knob is fit to SW when setting.
Insert
the FPC
Insert
the hook
A
Detail
of portion A (assemble the LAN/MODEM HOLDER)
LAN/MODEM
HOLDER
Put
the claw under the
MAIN
PCB.
S2
CAUTION
S1:Insulation
S2:Pinching Cables S3:Sharp Edge
S4:Part
No. Check S5:Others
Safety
Working
Figure
from oblique view
Put
the cables into the hollow
space
of the HOLDER.
HDD
Connector Guide
Screw
Screw
Screw
Screw
Screw
Screw
Thermal
Rubber
DIMM
Holder
RF
SW Knob
Screw
