Chapter 6 - Configuration Examples
97
With a dial-up line and an async modem, the Mode needs to be Asynchronous (the default) and the
Connection Method needs to be either Answering or Dialing. For the Mounds View site it needs to be
Answering.
With a leased line, the Mode needs to be Synchronous and the Connection Method needs to be Direct
Connect/Leased Line.
For a dial-up connection, perform steps 11,12,and 13 and then skip to step 15.
For a leased line connection, skip to step 14.
11. Change the connection method to Answering by clicking on the Direct Connect/Leased Line check box.
For the Mounds View LAN, the WAN Port Setup dialog box should have the following fields checked:
x Port Enable x Asynchronous
x 115200
x Answering
12. Click on the Advanced button to display the WAN General Setup dialog box.
13. Click on the Modem Types drop down text box and click on your modem type. If your WAN device is not
listed in this text box, click on the Add Modem button to display the Modem Types dialog box.
