3-56 TranSphere TS Wireless Extended Range IP Networking Transceivers – January 2008 GFK-2489
3
Transmitter Test Menu
This menu allows testing of the radio transceiver RF transmitter section (power amplifier).
Selections of specific frequencies and key duration, as well as transmit key behavior, can be
modified from this screen. This function is useful for troubleshooting specific radio amplifier
issues.
Transmitter Test Menu
A) Frequency 916.000000 Mhz
B) Duration 600 seconds
C) Tx Key Normal
Select a letter to configure an item, for the prev menu
▪ Frequency —Used to set the carrier frequency used during transmitter testing.
[900 MHz radios: 902.200000-927.600000; 916.000000 MHz]
[2.4 GHz radios: 2400.00000-2483.500000; 2400.000000 MHz]
▪ Duration —Sets the key duration time for transmitter testing. [1-600 seconds; 600]
▪ TX Key —Used to activate the transmitter on the test frequency. There are two modes:
Normal and Forced. Normal is the default selection, and keeps the transmitter in standard
frequency hopping configuration. Forced keys the transmitter on the specified test
frequency. [Normal, Forced; Normal]
