5-10 TranSphere TS Wireless Extended Range IP Networking Transceivers – January 2008 GFK-2489
5
13. The final screen displays all the previous settings for your review. The settings
should be:
• COM2 Port Status: Enabled
• COM2 Mode: Serial to Serial
• COM2 Remote Unit ID: [Unit ID displayed]
• COM2 Remote COM Port: COM2
• COM2 Baud Rate: 19200
• COM2 Byte Format: 8N1
• COM2 Buffer Size: 256 Bytes
• COM2 Inter Packet Delay: 4 Character lines
Serial Configuration Wizard Menu
A) Com 2 Port Status enabled
B) Com 2 Mode Serial to Serial
C) Com 2 Remote Unit ID 1155999
D) Com 2 Remote COM Port Com 2
E) Com 2 Baud Rate 19200
F) Com 2 Byte Format 8N1
G) Com 2 Buffer Size 256 Bytes
H) Com 2 Inter-Packet Delay 4 Character Times
X) Commit Changes and Exit Wizard
Select a letter to configure an item, for prev menu, ‘Q’ to quit wizard
If the settings shown on screen match the ones listed above, press X to commit the changes
and exit the Serial Configuration Wizard.
If not, press the letter of the item to change, press SPACE to cycle through the choices, then
press ENTER to accept the displayed choice. Then press N as many times as necessary to
return to the settings display. When all the entries are correct, press X to commit the changes
and exit the Serial Configuration Wizard.
