GFK-2489 Chapter 3 AP Management 3-55
3
PING Utility Menu
The PING Utility Menu is used to verify IP connectivity with LAN nodes or Ethernet endpoints.
Ping Utility Menu
A) Address to Ping 169.254.0.100
B) Count 4
C) Packet Size 32
D) Ping
Select a letter to configure an item, for the prev menu
▪ Address to Ping —Address to send a PING. [Any valid IP address]
▪ Count
—Number of PING packets to be sent.
▪ Packet Size —Size in bytes of each PING data packet.
▪ Ping —Start sending PING packets to address shown on screen. The process can be
stopped at any time by pressing CTRL C on the PC keyboard.
The screen then displays a detailed report of
PING
activity. Press any key after viewing the
results to return to this menu.
Authorization Codes Menu
Authorization Codes Menu
A) Authorization Key
Authorized Features
NETview MS enabled
DNP3 Handling enabled
Select a letter to configure an item, for the prev menu
▪ Authorization Key —Accept an Authorization Key into the transceiver non-volatile
memory.
▪ Authorized Features
(display only)—Presents a list of authorized features.
