GFK-2489
Chapter 2 Tabletop Setup and Evaluation 2-11
2
Observe the transceiver LEDs on the top cover for the proper indications. In a normally -
operating system, the following LED indications should be seen within 30 seconds of start-up:
▪
PWR—Lit continuously
▪
LINK—Lit continuously (unless Sleep is enabled)
▪
ETH—On, or blinks intermittently
▪
COM1/COM2—Blinks to indicate data communications
The table below details the LED functions for Remotes and AP radios.
LED Label
Activity
Indication
ON
LAN or endpoint detected
Blinking
Data TX or RX
LAN/ETH
OFF
LAN or endpoint not detected
Blinking
Data TX or RX
COM1
(MGT System)
OFF
No data activity
Blinking
Data TX or RX
COM2
OFF
No data activity
ON
Primary power (DC) present
Blinking
Radio in “Alarmed” state
PWR
OFF
Primary power (DC) absent
LINK (AP)
ON
Lights when radio has finished its startup cycle.
Remains lit.
ON
Connected to an AP
LINK (Remote)
OFF
Not connected to an AP
