3-12 TranSphere TS Wireless Extended Range IP Networking Transceivers – January 2008 GFK-2489
3
Main Menu
The Main Menu is the entryway to all customer-definable features. The Device Name of the
radio that is being interrogated appears at the top of this and all other screens.
[device name}
Main Menu
A) Starting Information Screen G) Wireless Network
B) Network Configuration H) Statistics / Event Log
C) Radio Configuration I) Device Information
D) Local Serial Configuration J) Maintenance / Tools
E) Remote Serial Gateway K) Redundancy
F) Security Configuration L) DNP3 Routing
Select a letter to configure an item, ‘Q’ to exit menu
▪ Starting Information Screen —Select this item to return to the Starting Information
Screen.
▪ Network Configuration —Tools to configure the transceiver data network layer.
▪ Radio Configuration —Tools to configure the transceiver wireless (radio) functions.
▪ Local Serial Configuration —Tools to configure the AP COM1 and COM2 serial ports.
▪ Remote Serial Gateway —Tools to configure the data connections to the Remote
transceiver serial ports.
▪ Security Configuration —Tools to configure the transceiver security services.
▪ Wireless Network —Tools to manage Remote and AP databases, and manage Remote
radios.
▪ Statistics/Event Log —Tools to measure the radio and data layer network performance.
▪ Device Information —Top-level customer-specific and definable parameters, such as the
date, time, console baud rate, and device name information.
▪ Maintenance/Tools —Tools for upgrading and selecting firmware images and
configuration files, and applying Authorization Keys to change radio capabilities.
▪ Redundancy —Places the radio in a “1+1” redundancy-compatible mode. This mode is
specifically for use with MDS P22 packaged model chassis. Please check with your MDS
sales representative for available configurations.
▪ DNP3 Routing —This selection provides access to a submenu where DNP3 routing
attributes can be managed.
