5-8 TranSphere TS Wireless Extended Range IP Networking Transceivers – January 2008 GFK-2489
5
10.
The next screen prompts for the input serial data port. Press A and then press
SPACE to toggle to COM2. Press ENTER to accept the displayed selection. Then
press N to continue.
Serial Configuration Wizard Menu
Please choose which serial port on the remote radio(s)
that all of the data should be sent through.
A) Remote Port
Com 2
B) Continue Wizard
Select a letter to configure an item,
The next screen prompts for the baud rate and byte format.
Press A to set the Data Baud Rate. Press SPACE to cycle through the baud rate
options until “19200” is displayed. Press ENTER to accept the Data Baud Rate.
Press B to set the Data Byte Format. Press SPACE to cycle through the byte
format options until “8N1” is displayed. Press ENTER to accept the Data Byte
Format. Then press N to continue.
Serial Configuration Wizard Menu
Please choose appropriate baud rate and byte format
to be used while sending all of the serial data.
A) Data Baud Rate
19200
B) Data Byte Format
8N1
B) Continue Wizard
Select a letter to configure an item,
