5-2 TranSphere TS Wireless Extended Range IP Networking Transceivers – January 2008 GFK-2489
5
IP-to-Local Serial Port Application Configuration
IP-to-local serial connection (Local Serial Gateway)
Radio Location Menu Item Setting
AP (COM2) Port Status Enabled
Mode TCP
RX IP Port
30011 Baud
Rate 19200 Byte
Format 8N1 Buffer Size
256 Bytes
IP-to-Remote Serial Application Example
This configuration makes any data sent or received with the AP via an IP port number appear
via the serial port of a single Remote (or of all Remotes, if “Broadcast” is selected for Remote
ID).
IP-to-Remote Serial Application Configuration
TS Wireless Menu Item Setting
Radio Location
AP (COM2)
Remote ID 1155883
COM Port COM2
Mode TCP Server
Radio IP Port 30066
Remote radio (COM2) Mode COM2 in transparent data mode
Baud 19200
Format 8N1
Buffer 256
DelayChars 4
