GFK-2489 Chapter 3 AP Management 3-47
3
Radio Packet Statistics
The previous screen dealt with Ethernet-related information. The Radio Packet Statistics
menu contains statistics that relate directly to over-the-air transmission of data. It provides
valuable insight into the quality of the RF link between TS Wireless radios with respect to the
handling of data packets.
Radio Packet Statistics Menu
Overflow 0 Failed 0
No Ack 55 Over the Air Data 5575
Lost Data 0 Frags 6773
Timeout 0 Retries 4
Good Data 5630 Diags 211
A) Packets Received by Zone
Select a letter to configure an item, for the prev menu
▪ Overflow —TX packets with “LCP buffer overflow data” responses.
▪ No Ack —Number of packets that were sent but not acknowledged.
▪ Lost Data —TX packets lost; over-the-air retries exceeded.
▪ Timeout —TX data packets lost; contention timeout.
▪ Good Data —Data packets with CRC “good” responses.
▪ Failed —TX packets failed; data integrity failed.
▪ Over the Air Data
—Data packets successfully delivered over the air.
▪ Frags
—Total fragments of data received.
▪ Retries —Total number of times packets were re-transmitted.
▪ Diags —TX packets with “Remote not synchronized” data responses.
