3-28 TranSphere TS Wireless Extended Range IP Networking Transceivers – January 2008 GFK-2489
3
View Current Settings Screen—Unicast UDP Mode Example
A sample View Current Settings Screen for a system configured for Unicast UDP mode is
shown below. The selections are similar to the serial-to-serial example above, but some items
are UDP specific.
Serial Configuration Wizard Menu
A) Com 2 Port Status disabled
B) Com 2 Mode Unicast UDP
C) Com 2 RX IP Port 30011
D) Com 2 TX IP Address 00.0.0
E) Com 2 TX IP Port 1024
F) Com 2 Talkback Enable disabled
G) Com 2 Baud Rate 19200
H) Com 2 Byte Format 8N1
I) Com 2 Buffer Size 64 Bytes
J) Com 2 Inter-Packet Delay 4 Character Times
X) Commit Changes and Exit Wizard
Select a letter to configure an item, for prev menu, ‘Q’ to quit wizard
▪ Port Status
—This selection is used to enable or disable the serial data port for payload
data operation. Normally, COM1 is disabled to permit Console Terminal operation.
When COM1 is enabled for data, management of the radio through COM1 is disabled.
This problem can be remedied by typing the escape sequence SHIFT + + + followed by
ENTER. This restores COM1 to console terminal mode. You must log in again.
▪ Mode —Used to set the method the host uses to connect to the radio. [Serial, Network;
Network]
▪ RX IP Port —This selection is used to specify which local IP port address should be used
to receive data from the host, as well as the IP address and port number of the host to
send data to at the remote end.
▪ TX IP Address —This selection is used to specify the local IP address used to receive
data from the host, as well as the IP address and port number of the host to send data to
(at the remote end).
▪ TX IP Port —A dynamically assigned software port used by external applications such as
HMI interfaces, host polling programs, etc.
▪ Talkback Enable —Used to enable or disable Talkback mode. [Enabled, Disabled;
Disabled]
