GFK-2489 Chapter 3 AP Management 3-45
3
Remote Serial Gateway Statistics
The Remote Serial Gateway Statistics screen summarizes port activity for Remote Serial
Gateway entries that have been set up for IP-to-Remote serial data. These values are reset to
zero when a radio is restarted.
Remote Serial Gateway Statistics Menu
Index Unit ID Com IP Port State IN:P.B OUT:P.P
1 7717 2 30022 ICP: Listening 0.0 0.0
1 7720 2 30021 ICP: Listening 0.0 0.0
1 7741 2 30023 ICP: Listening 0.0 0.0
Select a letter to configure an item, for prev menu
(Both COM1 and COM2 will be shown, if applicable)
▪ Index —Sequential number assigned to the associated Remote.
▪ UnitID —The unit ID of the associated Remote.
▪ Com
—Communication port being monitored (COM1 or COM2).
▪ IP Port
—IP port associated with the listed device.
▪ State —State of the AP server for this Remote.[Listening; Connected]
▪ IN:P,B —Displays the incoming port byte count.
▪ OUT:P,B —Displays the outgoing port byte count.
