3-46 TranSphere TS Wireless Extended Range IP Networking Transceivers – January 2008 GFK-2489
3
Ethernet and Wireless Packet Statistics
The Ethernet/Wireless Packet Statistics menu shows vital data on packets and bytes sent or
received, and errors detected. The screen is updated about every three seconds.
Ethernet Packet Statistics Menu
Ethernet Wireless
Packets Received 443 Packets Received 440
Packets Sent 1309 Packets Sent 1383
Bytes Received 210746 Bytes Received 28728
Bytes Sent 79262 Bytes Sent 260872
Packets Dropped 0 Packets Dropped 0
Receive Errors 0 Receive Errors 0
Lost Carrier Detected 516
A) Clear Statistics B) Clear Statistics
Select a letter to configure an item, for the prev menu
▪ Packets received
—Packets received through the Ethernet port of the transceiver.
▪ Packets sent
—Packets send through the Ethernet port of the transceiver.
▪ Bytes received
—Data bytes received by this radio.
▪ Bytes sent
—Data bytes sent by this radio.
▪ Packets dropped —Received packets dropped from a lack of buffers.
▪ Receive errors —Packets discarded after more than five retries.
▪ Lost carrier detected —Number of times the carrier signal on the Ethernet port
has been missing. This count increase significantly when the Ethernet cable is
inserted or removed.
▪ Clear Statistics
—Resets the statistics counter.
Wireless Packet Statistics
▪ Packets received
—Over-the-air data packets received by this radio.
▪ Packets sent
—Over-the-air data packets sent by this radio.
▪ Bytes received
—Over-the-air data bytes received by this radio.
▪ Bytes sent
—Over-the-air data bytes sent by this radio.
▪ Packets dropped
—Received packets dropped from a lack of buffers.
▪ Receive errors —Packets that do not pass a Cyclic Redundancy Check (CRC). This may
be due to transmissions corrupted by RF interference.
▪ Clear Statistics
—Resets the statistics counter.
