5-12 TranSphere TS Wireless Extended Range IP Networking Transceivers – January 2008 GFK-2489
5
Point-to-Multipoint, Serial-to-Serial Application Example
The operation and data flow for this mode is very similar to a point-to-point serial-to-serial
application, except that it uses multicast addressing. The primary difference is that data
presented at the AP COM port is packetized and sent to all of the Remotes. Upon receiving
the packet all of the Remotes, the data is stripped out of the packet and sent from the COM
port. Likewise, data presented at any of the Remote COM ports is packetized, sent to the AP,
stripped, and sent from the AP COM port.
TS Wireless radio Menu Item Setting
Location
AP (COM2)
Port Status Enabled
Mode Serial-to-Serial
Remote UnitID Broadcast
Remote COM port COM2
Baud Rate 19200
Byte Format 8N1
Buffer Size 256 Bytes I
Inter-Packet Delay 4
Remote radio (COM2) Mode Data
Baud 19200
Format 8N1
Buffer 256
DelayChars 4
