GFK-2489 Chapter 7 Troubleshooting and Radio Tests 7-5
7
The following is a summary of how several screens in the TS Wireless MS can be used as
diagnostic tools. For information on how to connect to the TS Wireless MS, see “Step 3:
Configure the AP”
in chapter 2.
Ethernet Packet Statistics Menu
Ethernet Packet Statistics Menu
Ethernet Wireless
Packets Received 443 Packets Received 440
Packets Sent 1309 Packets Sent 1383
Bytes Received 210746 Bytes Received 28728
Bytes Sent 79262 Bytes Sent 260872
Packets Dropped 0 Packets Dropped 0
Receive Errors 0 Receive Errors 0
Lost Carrier Detected 516
A) Clear Statistics B) Clear Statistics
Select a letter to configure an item, for the prev menu
This screen provides detailed information on data exchanges between the radio being
viewed and the network through the network layer.
The most significant fields are Retries, Retry Errors, Receive Errors, and Lost Carrier
Detected. If the data values are more than 10% of their sent and received counterparts, or the
Lost Carrier Detected value is greater than a few dozen, there may be trouble with
interference, or a loss of the Ethernet signal. Note that this does not refer to the over-the-air
(RF) carrier, but only to the Ethernet carrier.
