4-16 TranSphere TS Wireless Extended Range IP Networking Transceivers – January 2008 GFK-2489
4
TX FREQ=—Sets or displays the carrier
frequency (in MHz) for transmitter tests. The valid range is 902.2–927.6
for 900 MHz radios, or 2400.6–2482 for 2.4 GHz radios.
UNIT=—The 32-bit user-programmable radio address, which
defaults to the radio serial number, but can be changed.
REBOOT Restarts the radio firmware.
Optional arguments:
SAME—Restarts the radio with the active firmware image
OTHER—Restarts the radio with the inactive image
APP1—Restarts the radio with Application Image 1
APP2—Restarts the radio with Application Image 2
SLEEP Sets or displays the low-power operating mode. These modes are commonly
used where power consumption must be kept to a minimum, such as in solar-
powered installations.
Optional arguments:
CMD—Displays all settable optional arguments and their current values.
You can copy this list to a text file as a record of your configuration.
DTRSENSE=—Select the level of RS-232 DTR signal used
by the endpoint device to wake the radio:
LOW: DTR Active LOW
HIGH: DTR Active HIGH
When WAKE is set to DTR, the radio will wake on receiving this signal
from the endpoint device.
HANGTIME=—Minimum wake time in milliseconds
(100–60000) before returning to Low Power mode.
INDICATOR=—Indicates whether or not the Sleep indicator LED
is active.
ON: Sleep Mode indicator is on
OFF: Sleep Mode indicator is off
MODE=—Set the mode as follows:
NONE: Normal operation; the radio does not sleep
