Removing the backplane assembly – FUJITSU TeamPoS 3000 XL User Manual
Page 66

TeamPoS 3000 XL and XL
2
Installation
D900000145
Issue 3
5-20
5.9.
Removing the Backplane Assembly
Caution: Be sure to observe all ESD precautions and power off procedures.
1.
Remove the rear panel (See Section 5.1.2).
2.
Disconnect the AC power cord from the controller.
3.
Remove the front panel (See Section 5.1.1). The yellow LED should be off (See Section
1.2).
4.
Unseat the motherboard assembly (See Section 5.2).
5.
At the rear, remove the locking screw on the right hand side of the backplane assembly.
Looking from the rear, the power supply is on the right.
