TeamPoS 3000 XL and XL
2
Maintenance
D900000145 Issue 3 7-25
12. Reinstall the back panel (See Section 5.1.2).
13. If this is an upgrade, install the upgrade label that comes with the upgrade kit to the side
of the unit near the serial number. (See Section 7.2).
7.7 Replacing Battery Backup
Caution: Be sure to observe all ESD precautions and power off procedures.
The partial backup battery is located on the front of the TeamPoS 3000XL on the left.
1. Remove the rear panel (See Section 5.1.2).
2. Disconnect the power cable from the controller.
3. Remove the front panel (See Section 5.1.1). The yellow LED should be off. (See Section
1.2).
4. Snap off the protective front metal covering.
