Labels
User’s Manual
7-13
PAPER
SPECIFICATIONS
Example 2:
If nonlabel areas
*1
must be removed, round label corners.
*1 Areas in which no labels adhere to the backing sheet.
*2 R stands for radius. R2 and R3 should be between 2 mm and 3 mm.
Figure 7–2
Recommended label formats
Label
Label
Label
Label
Label
Label
Label
Mount
Enlarged label:
Rounded (R2 to R3)*2 corners
Label
DL6400/6600 Book Page 13 Thursday, September 21, 2000 7:52 PM
