Labels
User’s Manual 7-11
PAPER
SPECIFICATIONS
Important:
1. The thickness of the backing sheet must be 0.1 mm (1/254 in) or
less.
2. The thickness of the label must be 0.1 mm (1/254 in) or less.
3. Label adhesion
Labels must satisfy the conditions below and not peel off easily.
4. Print area
The figure below shows the print areas on labels.
Winding drum diameter 27 mm
(1.06 in)
Winding angle 180°
Winding time 24 hours
Ambient temperature 40°C
Ambient humidity 30% RH
Label
Drum diameter:
27 mm (1.06 in)
Print area Print area
C
C
C C
B
A
D
B
Fold
Label
Area Size in mm (in)
A 2.54 (0.1) or more
B 6.35 (0.25) or more
C 2.54 (0.1) or more
D 25.4 (1)
*1
*1 Lines may not be fed neatly in the print area of D. A line spacing of 1/6 inch or more pre-
vents characters on adjacent lines from overlapping.
