User’s Manual
4-1
4
CHAPTER
LOADING
PAPER
Loading Paper
1. Turn on the printer power switch ( | ).
2. Press the PAPER PATH button on the control panel to select
FRONT TRACTOR. The FRONT TRACTOR lamp lights.
3. Move the paper guide back as indicated by the arrow in the figure.
(See “Installing the Paper Guide” on page 2-2.)
4. Open the front cover of the printer.
Loading
Continuous
Forms (Front)
Front cover
Power switch on ( | )
Paper guide
DL6400/6600 Book Page 1 Thursday, September 21, 2000 7:52 PM
