Installing the Ribbon Cassette
User’s Manual
3-3
INSTALLING
THE RIBBON
CASSETTE
1. Turn off printer power (❍).
2. Open the top cover of the printer and move the paper thickness
lever to D.
3. Manually move the print head to the left side so that it is one third
of the printer width from the left side.
Installing the
Ribbon Cassette
Top cover
Print head
Paper thickness lever
Power switch off (❍)
