FUJITSU DL6600Pro User Manual
Page 75
Labels
7-12
User’s Manual
5. Formats
Use the formats shown below to prevent peeled labels from causing
feed failures, print head damage, and other serious problems.
Example 1:
Leave the four corners and sides uncut between cut portions and do
not remove nonlabel areas
*1
.
This procedure completely prevents label peeling.
Label
Label
Label
Label
Label
Label
Label
Backing
sheet
Label
Enlarged label:
Leave several cuts on
each of the four sides.
Leave uncut portions
on the four corners.
DL6400/6600 Book Page 12 Thursday, September 21, 2000 7:52 PM
