Preparing the Ribbon Cassette
3-2 User’s Manual
1. Remove the two protective tabs used in shipment.
2. Release the ribbon lock.
3. Turn the knob clockwise to check that the ribbon moves smoothly.
Notice:
Adjust the paper thickness lever on the printer appropriately for the
forms used. Otherwise, the ribbon may come loose or paper may be
smeared by ink from the ribbon.
Preparing the
Ribbon Cassette
Remove the protective tabs
Knob
Lock tabs B
Release the ribbon lock
☞
