Getting Acquainted with the Control Panel
E-4 User’s Manual
Buttons
Button Function
ONLINE Switches the printer online or offline.
F1, F2, and F3 Scroll through the printer menu items to allow
selection of setup functions, items, and options.
Other specific functions are assigned by the
setup functions selected.
↓ ↑
Reverses the direction of the up or down arrows
shown in the display. For example, pressing this
button changes forward line feed (
↑
) to reverse
line feed (
↓
).
NEXT DISPLAY Displays the printer’s four basic menus.
LOAD/
UNLOAD Loads paper to the top-of-form position for
printing. Unloads (retracts) continuous forms to
the tractor or ejects cut-sheet paper.
PAPER PATH Selects the friction, front tractor, or optional
rear tractor for feeding paper.
