Page 58
User’s Manual
6-1
6
CHAPTER
CLEARING
PAPER JAMS
Clearing Paper Jams
When using front-fed continuous forms, remove jammed paper as
follows:
1. Turn off printer power ( ❍ ).
2. Open the front cover.
3. Raise the cut-sheet tray.
4. Lower the green left and right jam removal levers.
Continuous
Forms (Front)
Front cover
Power switch off ( ❍ )
Cut-sheet tray
Jam removal lever
DL6400/6600 Book Page 1 Thursday, September 21, 2000 7:52 PM
