TUNE connector This female BNC connector is the DC tune voltage output if a tuneable DUT
or tuneable external reference is used.
Power switch The power switch disconnects the instrument from the DC input completely.
Caution:
Do not apply a DC voltage or current to the individual ports of the DC Control, DC Power and
RF Port. Applying a DC voltage or current may lead to the breakdown of this product. In
particular, there is the risk of the capacitor remaining charged. Connect the measurement
sample (DUT) to the port (or the test fixture, cables, etc. connected to the port) after
discharging DUT's electricity enough.
