3.9 FFT Analyzer Measurement
This tab is used to measure noise on one or two channels of the FFT analyzer. Select the frequency
range and the number of averages. Under “More” select either “Single Channel” or “Two channel
cross-correlated” measurement. Press start button to run measurement.
Figure 19 FFT Analyzer Mode
