12
VISA now allows you to communicate as a controller to the SERIES 7000.
2.4.7 Using Berkeley Nucleonics Application Programming Interface (API)
Please refer to the SERIES 7000 Programmer’s Manual to learn more about applying the API and
programming examples.
2.4.8 Installing the SERIES 7000 Graphical User Interface Software
Berkeley Nucleonics’s graphical user interface provides an intuitive control of the SERIES 7000. The
Java based application runs under any Operating System including Windows™ 2000, XP, Vista, 7, or
8 with standard requirements. Only the Java runtime environment must be installed on the PC.
To install the GUI on the computer, insert the SERIES 7000 Software and Manual CD into the
CD/DVD drive or download the latest GUI setup file from the Berkeley Nucleonics website. If the setup
doesn’t start automatically double click on the setup.exe to run the auto-installer.
The self-extracting setup provides easy installation and de-installation of the software. The setup
program guides you in a few steps though the installation process. In case the Java Runtime
Environment is not installed on your current computer, the setup procedure automatically will assist
you with the installation of the required version. For this you will need an internet connection.
2.4.9 Troubleshooting the LAN Interconnection
Software does not install or start properly
• Make sure your installation CD is not damaged.
• Verify that the Java Runtime Environment is installed
Software cannot detect any SERIES 7000
• Make sure you have connected both PC and SERIES 7000 to a common network.
• If connecting with USB, make sure that the IVI drivers have been installed during GUI
installation (default). The drivers can be reinstalled using the GUI setup procedure.
• Note that detection of the SERIES 7000 can take several seconds if your PC is configured to
work with an external DHCP server but the DHCP is not available. In some cases the
connection may even fail completely. Check your NIC configuration using IPCONFIG tool.
IPCONFIG /RELEASE and IPCONFIG /RENEW will update the NIC IP. Preferably work with
fixed IP instead.
• Make sure that your (software) firewall enables the SERIES 7000 software to setup a TCP/IP
connection within the LAN. Under Windows XP you can do that like this:
Open Control Panel under Settings in your Start menu. Then go to Windows Firewall. Click on
Exceptions and then add Program. If the SERIES 7000 Software is in this list choose it and
click OK otherwise you have to browse for the path to Berkeley Nucleonics Software. Finally
close all open dialogs with OK. Now your Windows™ Firewall is ready for SERIES 7000.
