Page 93
100K-2GSR Winch MountAssembly
Drawings 93
ITEM
Q TY.
PART NO ./DESC RIPTIO N
CO MMENTS
1
1
20223 W inc h Mount Assembly
2
1
H59 W inc h Assembly , Manual
3
1
59R Roller Assembly , W inc h
4
1
20286 W inc h Cover
5
4
20203 Spac er, W inc h
6
2
806542-1_3.4-16 x 4.50 Hex Bolt
7
4
91074A036 Loc k W asher Assembly , 3.4
8
2
806542_3.4-16 X 4.50lg. Soc . Hd. Cap Sc rew
9
6
806284_1.2-13 x 2.00lg. Hex Bolt
10
8
810703_1.2 Loc k W asher
11
2
806244_1.2-13 x 1.0 Hex Bolt
12
2
2061-10-8S_10MORB x 8MJ IC Fitting 45
13
1
2081-4-2S 1.4 x 1.8 H.P. Hex Bushing
14
1
2047-2-2S 2MNPTX2FNPT Fitting 90 Drg Swivel
15
1
C028 W inc h Cable Spring
16
2
G2130-5.8 Shac kle
