100K-2GSR Main Manifold Air Connections
Drawings 111
DUPLICATE PORT DESCRIPTION COLOR SIZE
A AIR SUPPLY BLACK 3/16
B AIR SUPPLY TORQUE YELLOW 5/32
C AIR SUPPLY SPIN CLEAR 5/32
1 AIR SUPPLY W INCH RED 5/32
X 2 GRIP #1 YELLOW 5/32
3 GRIP #2 ORANGE 5/32
4 GRIP #3 BLUE 5/32
5 RAISE VALVE SIDE "b" GREEN 5/32
X 6 LOW ER VALVE SIDE "a" BLACK 5/32
X 7 TILT VALVE SIDE "b" CLEAR 5/32
8 TILT VALVE SIDE "a" GREY 5/32
9 OILER BLACK 5/32
DUPLICATE PORT DESCRIPTION COLOR SIZE
A SUPPLY FRONT FILTER AIR 1 CLEAR 3/16
B SUPPLY RETURN BLACK 3/16
C SUPPLY TORQUE YELLOW 5/32
1 SUPPLY W INCH RED 5/32
2 SUPPLY SPIN CLEAR 5/32
3 TORQUE VALVE SIDE "a" GREY 5/32
4 TORQUE VALVE SIDE "b" BLUE 5/32
5 SPIN VALVE SIDE "b" GREEN 5/32
6 SPIN VaLVE SIDE "a" ORANGE 5/32
7 W INCH VALVE SIDE "b" BLACK 5/32
X 8 W INCH VALVE SIDE "a" GREY 5/32
X 9 SPARE GREEN 5/32
LEFT CONNECTOR
RIGHT CONNECTOR
