100K-2GSR Hydro-Pneumatic Assembly
Drawings 85
ITEM QTY. PART NO./DESCRIPTION COMMENTS
1 1 100K-2GSR Hydraulic Connections (J1A-A) See Explosion
2 1 20169 Control Housing Assembly
3 1 20176A Block Plate Assembly
4 1 20167-2 Inspection Cover
5 1 20167-3A Inspection Cover
6 1 20162A Control Housing Assembly
7 8 806244_1.2-13 x 1.0 Hex Bolt
8 14 810703_1.2 Lock W asher
9 8 810705_1.2 Flat W asher
10 6 806239_1.2-13 x .75lg. Hex Bolt
11 4 806003_3.8-16 x .75 lg. Hex Bolt
12 8 810645_3.8 Lock W asher
13 4 806004-1_3.8-16 x .75 Lg. Hex Bolt Drilled
14 1 A11-1LCH Multiplex Connector Assembly See Explosion
15 1 A11-2RCH Multiplex Connector Assembly See Explosion
16 1 A11-RT_Right Control Tube Assembly See Explosion
17 1 A11LFT Left Control Tube Assembly See Explosion
18 2 20400 Grommet
19 1 9307K62 Grommet
