100K-2GSR Main Manifold Assembly
Drawings 109
VALVE ADJUSTMENT
FUNCTION
PORT
PRESSURE/ADJUSTMENT
RAISE/LOWER CYL
R/L
Flow Cntrl. Valve (H6); Screw in for FASTER mvmnt., out for SLOWER
mvmnt. (top screw LOWER adj., bottom UPPER adj.)
BOTTOM WRENCH
GRIP1
Pressure (H6P) Preset to 1000psi; Screw in for higher pressure, out for lower
pressure; Flow Cntrl. Valve (H6); Screw out for more flow, in for less flow
MIDDLE WRENCH
GRIP2
Pressure (H6P) Preset to 1000psi; Screw in for higher pressure, out for lower
pressure; Flow Cntrl. Valve (H6); Screw out for more flow, in for less flow
UNIT TILT
TILT
Flow Cntrl. Valve (H6); Screw in for faster mvmnt., out for slower mvmnt.
(top screw FORWARD tilt, bottom for BACKWARD tilt)
WINCH
WINCH
Flow Cntrl. Valve (H6); Screw in for faster mvmnt., screw out for slower
mvmnt.
MOTOR SEQUENCE
MSEQ
Sequences the spinner motor to begin turning at the correct time; 3/16" socket
wrench turn in to delay motor start, turn out to advance motor start
ITEM
QTY.
PART NO./DESCRIPTION
COMMENTS
1
1
J1A-A Main Manifold
2
1
V6APBCP_DO5_Assembly
3
1
V6ABT_DO5_Assembly
4
2
H7 Pilot Check Sandwich Assembly
5
5
H6 Flow Control Sandwich Assembly
6
2
H53S Directional Valve Assembly
7
2
H93S Directional Valve Assembly
8
3
H6P Pressure Control Sandwich
9
1
H4B Air Piloted 2-Way Valve
10
1
V6SR_DO5_Assembly
11
1
H9JR 3Grip Valve
12
1
H5 Directional Valve Assembly
13
16
A46 5.32 x 1.8 PTC Elbow
14
1
2082-4S_1.4 Pipe Plug
15
2
9005912-12S_MORB Plug
16
1
H35 Sequence Valve
17
1
H72 Sequence Valve
18
1
2216-2-4S_-4MORB x-4FNPT Str. Adaptor
19
1
2047-2-2S 2MNPTX2FNPT Fitting 90 Drg Swivel
20
1
HOS-OIL_1.8MNPTx1.8MNPTx130 lg_1.8 Hose
21
4
202702-6-4S_-6MORB x -4MJIC Str. Adaptor
22
2
202702-6-8S_-6MORB x -8MJIC Str. Adaptor
23
3
202702-8-8S_-8MORB x -8MJIC Str. Adaptor
24
1
2062-6-6S_6MORB x 6MJIC Fitting 90
25
1
206209-6-6S_6MORB x 6MJIC Fitting 90 Ext.
26
2
206209-10-10S_10MORB x 10MJIC Fitting 90 Ext.
27
2
2062-10-10S_10MORB x 10MJIC Fitting 90
28
1
900598-8S_MORB Plug
29
6
202702-6-6S_-6MORB x -6MJIC Str. Adaptor
30
4
900598-6S_MORB Plug
31
1
H94S Directional Valve
32
2
2216-1212S Adaptor, Hydraulic
33
1
2081-4-2S 1.4 x 1.8 H.P. Hex Bushing
34
1
A47 3.16 x 1.8 PTC Elbow
35
1
A48 1.4 x 1.4 PTC Elbow
36
4
DO5 O Ring, Viton
37
4
D03 O Ring, Viton
