100K-2GSR Winch Assembly
ITEM QTY. PART NO./DESCRIPTION COMMENTS
2 1 061-W 202-2-25 W orm Shaft
3 1 061-W 203-2-25 Bronze Gear
4 1 061-W 204 Drum
6 1 061-W 206 Gear Case Cover
7 1 061-W 207-K Yoke Kit
8 1 061-W 208 End Bearing
10 1 061-W 210-K Gear Case Cover Gasket Kit
13 1 061-W 213 Spring
14 1 061-W 214 Friction Block
16 1 061-W 216 Oil Seal
17 2 061-W 217 Key
18 1 061-W 218 Drum Shaft
20 1 061-W 220 Retaining Ring
23 1 061-W 223 Clutch Dog
24 2 061-W 224 Bearing Cap
25 2 061-W 225 Bearing Cone
26 3 061-W 226 Pipe Plug
27 6 061-W 227 Ht Cap Screw
28 2 061-W 228 Socket Set Screw
29 1 061-W 229 Socket Set Screw
32 1 061-W 232 Bearing Cap
33 1 061-W 233 Bearing Cone
34 1 061-W 234 Bearing Cap
35 1 061-W 235 Bearing Cone
36 1 061-W 255 W ide Spacer
37 1 061-W 237-K Motor Gasket Kit
49 2 061-W 249 Hex Head Screw
50 1 061-4369 Key
52 1 061-3847 Motor
65 1 061-W 265 Gear Case
66 1 061-W 266 Clutch Housing
67 1 061-W 267 Clutch Lever
79 1 061-W 279 Spring
80 1 061-W 280 W asher
163 Drawings
NOTE
When ordering winch parts, specify Serial No. and Model stamped on winch cover.
