7

Piping

Section 4

General

Note

All plumbing work must be performed by a qualified technician. Always follow all local, state and

provincial codes.

A proper installation requires a pressure relief valve, a ¼" female N.P.T. threaded fitting for the pressure sensor,

and properly sized pipe. Piping should be no smaller than the pump discharge and/or suction connections.

Piping should be kept as short as possible. Avoid the use of unnecessary fittings to minimize friction losses.

Some pump and motor combinations supplied with this system can create dangerous pressure.

Select pipe and fittings accordingly per your pipe suppliers’ recommendation. Consult local codes

for piping requirements in your area.

All joints must be airtight. Use Teflon tape or another type of pipe sealant to seal threaded connections. Please

be careful when using thread sealant as any excess that gets inside the pipe may plug the pressure sensor.
Galvanized fittings or pipe should never be connected directly to the stainless steel discharge head or casing as

galvanic corrosion may occur. Barb type connectors should always be double clamped.

Pressure Tank, Pressure Relief Valve and Discharge Piping

Use only “pre-charged” tanks on this system. Do not use galvanized tanks. Select an area that is always above

34º F (1.1º C) in which to install the tank, pressure sensor and pressure relief valve. If this is an area where a

water leak or pressure relief valve blow-off may damage property, connect a drain line to the pressure relief

valve. Run the drain line from the pressure relief valve to a suitable drain or to an area where water

will not damage property.

Pressure Tank, System Pressure

Sizing – A diaphragm tank (not included) is used to cushion the pressure system during start-up and shut-

down. It should be sized to at least 20% of the total capacity of your pump. Example: If your pump is sized for

100 GPM then size your tank for at least 20 gal. total volume, not draw down. Pre-charge your bladder tank to

10-15 PSI below your system pressure. The controller is pre-set for 50 PSI at the factory. Therefore a 35-40 PSI

pre-charge in your tank would be required. Use the higher tank pre-charge setting if the system drifts over

5 PSI at a constant flow rate. NOTE: Pre-charge your tank before filling with water!

Caution

Maximum working pressure of HydroPro diaphragm tank is 125 psi.

Installing the Pressure Sensor

The pressure sensor requires a ¼" FNPT fitting for installation. Install the pressure sensor with the electrical

connector pointing up to avoid clogging the pressure port with debris. Install the pressure sensor in a straight

run of pipe away from elbows or turbulence. For optimum pressure control install the pressure sensor in the

same straight run of pipe as the pressure tank. Ensure the pressure sensor is within 10ft of the pressure tank.

Installing the pressure sensor far away from the pressure tank may result in pressure oscillations. Do not

install the pressure sensor in a location where freezing can occur. A frozen pipe can cause damage to the

pressure sensor.

Hazardous

Pressure

CAUTION

Hazardous

Pressure

CAUTION
