System design – ITT S-DRIVE IM213 User Manual
Page 6

6
Section 3
(continued)
Diagram #2 shows a set-up for municipal water connection.
System Design
FLOW
AIR
4
8
6
3 PHASE OUTPUT
TO MOTOR
5
1
2
SUCTION
3
8
9
7
1 SPD CONTROLLER
6
AIR DIAPHRAGM TANK
2 FUSIBLE DISCONNECT
7
3 PHASE MOTOR
3 CENTRIFUGAL PUMP
8
GATE VALVE (BALL VALVE)
4 CHECK VALVE
9
PRESSURE GAUGE
5 PRESSURE TRANSDUCER (CABLE ASSEMBLY) 10 PRESSURE RELIEF VALVE
NOTES: For single phase input power, use L1 and L3 terminals and adjust motor overload switches
to 50% of controller rating or lower.
9
T1
T2
T3
L1
L2
L3
SUPPLY POWER
GND
GND
10
