78 Using the Command Line Interface
If the Enter key is selected, the next page of trace levels appears as follows:
Figure 55 Trace settings
Enter a level number from the Trace Settings that are shown. This toggles the current setting to either ON or
OFF.
Select U to update current operating trace levels. This option forces the currently displayed trace settings to
become effective immediately, without requiring a reboot or power cycle.
NOTE: Be sure to set the clock and date in the Real-Time Clock Configuration menu so event logging is
accurate.
Event configuration
This option allows selecting the event threshold for filtering event logging. The asterisk denotes the current
setting.
Figure 56 Event filter settings
Trace Settings
X.XX.XX XXXXXX XXXXXXXXXXXXXXXX
07/7/2005 08:56:22
0) SG List : OFF
1) Timing : OFF
2) FCP/RMI : OFF
3) AF : OFF
4) INBAND : OFF
5) Multi-Host Lib : OFF
6) Queue Element : OFF
U) Update Current Operating Trace Levels
X) Return to previous menu
Enter the trace level index, for next page >
Event Filter Settings
X.XX.XX XXXXXX XXXXXXXXXXXXXXXX
07/7/2005 08:56:22
1) Disable Event Logging 6) Warning events
2) Emergency events 7) Notify events
3) Alert events 8) Info events
4) Critical events 9) Debug events
5) Error events 0)* Log all events
U) Update Current Operating Trace Levels
X) Return to Previous menu
Enter event threshold <0-9> >
