Page 119

•

Select 2. The following menu appears:

Figure 79

Ethernet configuration menu

Select 7 to toggle the DHCP setting. When DHCP is enabled, this activates Dynamic Host Configuration

Protocol and allows the network storage router to be assigned a dynamic IP address from a DHCP server

located on the Ethernet network used by the network storage router.
For descriptions of other menu selections, refer to ”

Once DHCP is enabled, it is necessary to save the current configuration and reboot the network storage

router before DHCP will operate.

NOTE:

For the IP address, Subnet Mask, and IP Gateway address, it is okay to have null values prior to

rebooting the network storage router. However, if these settings have null values after a reboot, then this

indicates the DHCP Server was unable to acquire the information for that setting. See the note below for

more information.

Use the following steps to save the current settings and reboot the system:

Select X) Return to previous menu.

Select A) Save Configuration.

Select X) Return to previous menu.

Select 4) Reboot.

After the network storage router finishes rebooting, the Main Menu will appear. DHCP status can be

verified from the Ethernet Configuration Menu where DHCP Configuration is indicated as “Enabled” if

Ethernet Configuration Menu

X.X.XX XXXXXX XXXXXX-XXX_XXXXXXXXXXXXXX

07/7/2005 08:56:22

IP Address : 1.1.1.1

Subnet Mask : 255.255.255.0

IP Gateway : 0.0.0.0

Ethernet Physical Address : 08:06:07:05:03:09

Ethernet Mode : 10/100Mbps (Auto-Neg)

Hostname :

DHCP Configuration : Disabled

1) Change IP Address

2) Change IP Subnet Mask

3) Change IP Gateway

4) Change Ethernet Physical Address

5) Toggle Ethernet Mode

6) Change Hostname

7) Toggle DHCP Configuration

8) Change Security Settings

X) Return to previous menu
