Page 73

Remove gaps

NOTE:

SCSI devices attached to a Fibre Channel port must be mapped as sequential FC LUNs starting at

LUN number 00. Skipping LUN numbers is not recommended when mapping FC LUNs because FC

Discovery stops the discovery process whenever an empty LUN position is found.

This option removes any incremental gaps in the sequence of LUNs listed in the table.

Deleting an entry

The user selects a LUN ID.

Figure 48

Deleting an entry

Select D to delete multiple LUNs:

NOTE:

When deleting multiple LUNs, the user can list the LUNs to delete in a comma or space delimited

format.

•

Select 3 from the Map Edit menu to clear (that is, remove all entries from) the current map. The user is

prompted for confirmation.

•

Select 4 from the Map Edit menu to fill the current map. This selection scans the device list and appends

all unmapped devices at the end of the current map. Devices marked as DOWN are not mapped. After

this operation completes, the Edit Map Entries screen appears.

•

Select 6 from the Device Mapping Main menu to clone current map. This option allows the user to

make an exact copy of an already existing map complete with all entries. Cloning of Auto Assigned or

SCC Map is not allowed. The new map must have a unique map ID and name. Once cloning is

complete, the newly created map becomes current map. The purpose of this option is to create a base

for a new map that is similar to an already existing map.

•

Select 7 from the Device Mapping Main menu to edit the host list for the current map. The current map

can be associated with hosts available in the host list on the same port where the map is defined.

Initially all hosts are associated with an Indexed map. These are built at runtime hosts. They cannot be

edited or deleted; their name cannot be changed.

Select LUN to delete (X=Cancel, D=DeleteMulitple) > 0

Are you sure you want to delete LUN 0? (Y=Confirm, X=Cancel) > y
