N1200-320 4Gb Network Storage Router user and service guide 47
Mapping menu
Accessed from the Main menu, the Mapping menu is used to create or edit LUN maps and assign them to
hosts. (see Figure 27 ).
Figure 27 Mapping screen
NOTE: Indexed, Auto Assigned, and SCC maps cannot be deleted or renamed.
NOTE: SCC and Auto-Assigned maps cannot be cloned.
Each physical port/bus on the network storage router can have the following maps:
Each map has a unique name and map ID; one of the maps must be identified as the current map.
Fibre Channel mapping tasks
Configuration tasks for Fibre Channel mapping includes:
• Viewing and changing Fibre Channel map information
• Viewing and changing Fibre Channel host information
Each task is discussed in the following paragraphs.
Table 4 Device map types
Map type Generated by Editable
Auto Assigned System No
Indexed (default) System Yes
Port 0 Device Map System Generated/User Edited Yes
SCC System No
