N1200-320 4Gb Network Storage Router user and service guide 67
Parallel SCSI configuration
This menu allows for setting up SCSI attributes.
Figure 42 Parallel SCSI configuration menu
Press the Enter key to toggle the current menu to the next SCSI bus.
• Select 1 to edit the SCSI Initiator menu settings, described later in the chapter.
• Select 2 to enable/disable SCSI Discovery.
• Select 3 to enable/disable SCSI bus Reset on Boot. When enabled, the network storage router
automatically resets SCSI buses after initial library power-up and after reboots.
• Select 4 to set the discovery delay time for SCSI devices. The default is 30 seconds. This is the time the
network storage router waits after a power-up or reboot before starting to discover SCSI devices. This
value should be set to no less than 250ms, according to the SCSI standard for Reset-to-Selection Time.
This value may need to be increased to ensure that all SCSI devices complete their individual
power-ups. With Discovery enabled, the Discovery Delay lengthens the time taken by the network
storage router to reboot.
• Select 5 to toggle the SCSI termination mode between Enabled and Disabled. This option is
automatically set to Enabled for Internal termination. The Internal setting allows the network storage
router to internally terminate a SCSI connection. Setting this option to Disabled allows the SCSI bus, not
the network storage router, to handle SCSI terminations.
• Select 6 to access menu settings for the maximum SCSI bus connection speed, described later in this
chapter. Note that when this option is selected, the user is prompted to select a Target ID on the
currently selected bus. Currently, maximum speed settings are shown.
Parallel SCSI Configuration Menu
X.XX.XX XXXXXX XXXXXXXXXXXXXXXX
07/7/2005 08:56:22
Current SCSI Configuration - Bus 0
Discovery : Enabled
Bus Reset on Boot : Enabled
Discovery delay time : 30 seconds
Internal Termination : Enabled
1) Edit Initiator Settings
2) Enable/Disable SCSI Discovery
3) Enable/Disable SCSI Reset on Boot
4) Set Discovery Delay Time
5) Set SCSI Termination Mode
6) Set Maximum SCSI Bus Connect Speed
X) Return to previous menu
Command, for next bus >
