Set
Fixture
External
SVideo
NTSC_M
NTSC_MJ
PAL_B
PAL_D
PAL_G
PAL_H
PAL_I
PAL_M
PAL_N
SECAM_B
SECAM_D
SECAM_G
SECAM_H
SECAM_K
SECAM_K
1
SECAM_L
SECAM_L
1
Identifies the SVideo format used for video input.
Projector
Factory
Defaults
On
Restores factory default settings
Off
Default
Projector
Input
External
Chooses the input the Projector will accept
Internal
Projector In
by DMX
Yes
Selecting Yes allows projector’s input source to be
selected from DMX
No
Disables changing projector input via DMX
Projector
Lamp
On
Manually turns Projector Lamp on
Off
Manually turns Projector Lamp off
Projector
Startup
Mode
Always
Turns the projector lamp on whenever the fixture is
connected to power
Manual
Turns on the projector lamp when Projector Lamp =
On
DMX
Turns the projector lamp on with DMX
input (default)
Projector
OSD Menu
On
Navigation buttons control Projector Menu System
Off
Navigation buttons control Fixture Menu System
Zoom
Override
On
On Overrides the DMX values sent by the console.
Set value manually from 0-255
Off
Focus
Override
On
On Overrides the DMX values sent by the console.
Set value manually from 0-255
Off
Projector Defaults
Selecting button restores Factory Projector
Defaults
Projector
Ceiling
On
Rotates the image 180 degrees
Off
Default
Projector
Rear
On
Inverts the image for projection from behind a
screen
Off
Settings do not match factory defaults
