CHAPTER 16
Content Management Application (CMA)
DL.2 Digital Light User Manual 209
Mainboard Current Temperature Read only
Mainboard Maximum Temperature Read only
Mainboard Minimum Temperature Read only
Mainboard Temperature Reset Pressing Reset restores value to Current Temperature
Model Read only
Pan Invert
On Inverts pan positioning
Off reverts to default position
Pan/Tilt Swap
On swaps pan and tilt positioning
Off reverts to default positioning
Projector Control Menu
On access the Projector menu
Off reverts to DL.2 menu
Projector Defaults Selecting this option automatically restores projector defaults
Projector Focus Value 0-255
Projector Input
External accepts input from an external video source
Internal accepts input from the graphics engine
Projector Input Selection
by DMX
Yes allows projector input to be switched via DMX
No disables projector input switching via DMX
Projector Startup Mode
Always Onturns lamp on when the fixture is plugged in
Manual turns lamp on only if the Lamp is set to On
DMX turns lamp on if DMX is present
Projector Lamp On
On
Off
Projector Zoom Value 0-255
Upgrade Content Press Upgrade to upgrade stock content
Restore Settings Press Restore to revert to factory fixture settings
Self Test Focus
On tests focus mechanical functionality
Off stops self test
Self Test Iris
On tests Iris mechanical functionality
Off stops self test
Self Test Pan/Tilt
On tests Pan and Tilt mechanical functionality
Off stops self test
Self Test Video Pattern Select from a list of Patterns to test graphics engine functionality
Self Test Zoom
On tests Zoom mechanical functionality
Off stops self test
Reboot Press Reboot to restart the internal graphics engine
Software Version Read only
Start Channel 0-255
External SVideo Format
NTSC_M NTSC_MJ PAL_B PAL_D
PAL_G PAL_H PAL_I PAL_M
PAL_N SECAM_B SECAM_D SECAM_G
SECAM_H SECAM_K SECAM_K1 SECAM_L
SECAM_L1
Tilt Invert
On Inverts Tilt positioning
Off reverts to default position
Unique Number Read only
Configuration Item Configuration Value Options
