CHAPTER 17
Maintenance and Troubleshooting
DL.2 Digital Light User Manual 217
3. Disconnect power to infrared illuminator.
4. Inside the bezel, locate the two Phillips head screws and washers securing the front window
in place.
5. Remove the screws, making sure not to misplace the washers.
6. Clean the front window using a mild glass cleaner (containing no ammonia) and a soft, lint-
free cotton cloth.
7. If the window needs replacement, use the part specified in Related Products and Optional
Accessories on page 4.
8. Carefully replace the Phillips screws and washers, making sure not to break the glass.
CAUTION!
Use plastic washers only when replacing the front
glass. Using metal washers can damage the glass.
9. Reconnect power to the infrared illuminator
10. Replace the front bezel.
Replacing Motor Driver Board
WARNINGS!
Disconnect power before servicing.
Replace fuses with the specified type and rating only.
Equipment surfaces may reach temperatures up to
130° C (266° F). Allow the fixture to cool before
handling.
s
The DL.2 fixture is designed with two motor driver boards:
1. The board that controls the motors for the tilt, focus, zoom, and iris functions as well as
fans is located in the fixture head.
2. The board that drives pan motor and fans is located in the base housing.
All cabling is marked with labels corresponding to locations on board for easy replacement.
When changing a board, align the screw holes and standoffs to ensure correct orientation in the
fixture.
CAUTION!
The fixture will not function correctly if contact screws
are missing from driver boards.
