DL.2 and Axon DMX Protocol
230
DL2 Digital Light User Manual
10
NA
Control
Function*
Lamp OFF (80)
90-98
NA
0
0
Reserved
99-119
Shutdown (80)
120-130
Reserved
131-144
Graphics System Reset (80)
145-149
Camera Reset
150-155
Home Pan/Tilt (20)
160-168
Reserved
169
Home Focus/Zoom/Iris (20)
170-178
Reserved
179
Using the Projector’s Menu System
Projector Menu
180-184
NA
Projector Up arrow
185-188
Projector Down arrow
189-192
Projector Left arrow
193-196
Projector Right arrow
197-200
Store menu selection
201-204
Projector Floor Orientation
Active
Commands
205-208
Projector Ceiling Orientation
209-212
Projector Front Projection
213-216
Projector Rear Projection
217-220
Changing Projector Inputs (Set Dimmer Channel = 0)
External RGBHV to Projector
221-224
NA
Graphics Engine to Projector (default)
225-228
Changing Graphics Engine Inputs (Set Dimmer Channel = 0)
S-Video In to Graphic Engine, Internal Camera to
Camera Out
229-232
NA
Internal Camera to Graphics Engine (default)
233-236
Reserved
237-255 93-100
Channel #
Function
Description
Value
Default
DL.2 Axon
dec.
%
dec.
%
*
To prevent inadvertent triggering, some Control Function options won’t activate until the value has been
held for a period of time. A number in parenthesis is the minimum number of consecutive times a DMX
value must be received from a controller before the operation begins.
