APPENDIX A
DL.2 and Axon DMX Protocol
DL2 Digital Light User Manual 271
Graphic 2 Scaling
124 103 Scale X
Minimum object size along X axis (1:10) 0 0
128 50
Increases object size along X axis from minimum
to actual size
1-127 1-49
Actual size along X axis (1:1) 128 50
Increases object size along X axis from actual to
maximum size
129-254 51-99
Maximum object size along X axis (10:1) 255 100
125 104 Scale Y
Minimum object size along Y axis (1:10) 0 0
128 50
Increases object size along Y axis from minimum
to actual size
1-127 1-49
Actual size along Y axis (1:1) 128 50
Increases object size along Y axis from actual to
maximum size
129-254 51-99
Maximum object size along Y axis (10:1) 255 100
126 105 Scale Z
Minimum object size along Z axis (1:10) 0 0
128 50
Increases object size along Z axis from minimum
to actual size
1-127 1-49
Actual size along Z axis (1:1) 128 50
Increases object size along Z axis from actual to
maximum size
129-254 51-99
Maximum object size along Z axis (10:1) 255 100
Graphic 2 Position
127
128
106
107
X-Position
Moves object left from center of display 0-36767 0-49
32768 50
Centers object along X axis in display 32768 50
Moves object right from center of display
36769-
65535
51-100
129
130
108
109
Y-Position
Moves object down from center of display 0-36767 0-49
32768 50
Centers object along Y axis in display 32768 50
Moves object up from center of display
36769-
65535
51-100
131
132
110
111
Z-Position
Moves object nearer from center of display 0-36767 0-49
32768 50
Centers object along Z axis in display 32768 50
Moves object back along Z axis at center of
display 36769-
65535
51-100
Channel #
Function Description
Value Default
DL.2 Axon dec. % dec. %
