The DL.2 Menu System
24 DL.2 Digital Light User Manual
DL.2 Menu Options
The menu display consists of a set of top-level tabbed screens and their associated subtabs.
Main
Tab
Sub-Tabs/
Screens
Fields
Controls
Options Function/Notes
DMX Control Source DMX512 Sets DMX as fixture communication source
Art-Net Set Universe field from 0-16 [Art-Net protocol]
Set Subnet field from 0-16 [Art-Net protocol]
Protocol Standard Motion + global + 3 objects = 170 channels
Dual Motion + global + 2 objects = 132 channels
Single Motion + global + 1 object = 94 channels
Fixture ID 1-255 Assigns the fixture a unique number on fixture
network
Start
Channel 1-512 Sets the fixture’s DMX start channel
Raw View Main Table Displays DMX values for all 512 DMX link channels
in rows of values.
Offset Scrolls through rows of DMX values
Refresh
Rate 0-44 Times/second for refreshing displayed values
Refresh
Timer On
DMX values updated instantly
Off
Display does not refresh
Protocol
View Motion Displays fixture Movement and Camera parameter
values
Global Displays Intensity, Iris, Edge Fade, Viewpoint and
Keystone correction parameters values for the
composite image
Obj 1 Displays Position, Rotation, Scaling, and Effects
parameters values for the selected graphic object
Obj 2
Obj 3
Set Fixture Pan Invert On Inverts the direction of the pan motor.
Off Default
Tilt Invert On Inverts the direction of the Tilt motor.
Off Default
Pan/Tilt
Swap On Swaps Pan and Tilt directions
Off Default
Data Loss
Timeout
Iris Long Closes iris after a 5 minute DMX data loss
Short Closes iris after a 5 second DMX data loss
Display On Default intensity
Note: Unless you select Off,
you can adjust display
intensity level.
adjustment
Preview Displays current
content preview
Off Turns off display after a period of time
Display
Invert On Inverts menu display and navigation
Off Turns off the display invert
Auto Automatically inverts display >45°
