CHAPTER 13
Effect Mode Options Descriptions
164 DL.2 Digital Light User Manual
Magnifying Lens Object Effect Global Effect
Effect Mode parameter DMX value = 36
This option applies spherical overlay that magnifies a portion of the texture to create a virtual
convex lens effect over a portion of the image. You can adjust the size of the lens and move it
over different areas of the image.
Modifier 1: Controls the horizontal position of the lens’ centerpoint from 0=left edge to 255
(100%) = right edge of output.
Modifier 2: Controls the vertical position of the lens’ centerpoint from 0=top edge to 255
(100%) = bottom edge of output.
Modifier 3: Controls the size of the lens from 0=smallest to 255 (100%) = largest.
Magnifying Lens
Object Effect Global Effect
2
Effect Mode parameter DMX value = 37
This option applies spherical overlay that magnifies a portion of the texture to create a doubled
virtual convex lens over a portion of the image. You can adjust the size of the lens and move it
over different areas of the image.
Modifier 1: Controls the horizontal position of the lens’ centerpoint from 0=left edge to 255
(100%) = right edge of output.
Modifier 2: Controls the vertical position of the lens’ centerpoint from 0=top edge to 255
(100%) = bottom edge of output.
Modifier 3: Controls the size of the lens from 0=smallest to 255 (100%) = largest.
Tip: Zooming in with this lens option creates an additional effect.
